CPU | LGA1700 socket; Supports Intel® 14th/13th/12th Gen Core™, Pentium® Gold, Celeron®; L3 cache varies (see GIGABYTE site for full list) |
Chipset | Intel® B760 Express |
Memory | 2 x DDR4 DIMM (up to 64 GB), 2133–3200 MT/s, Dual Channel, ECC/Non-ECC (Un-buffered), XMP support |
Onboard Graphics | Intel® HD Graphics: 1 x D-Sub (1920x1200@60Hz), 1 x HDMI (4096x2160@60Hz); HDMI 2.1, HDCP 2.3 |
Audio | Realtek® Audio CODEC, High Definition Audio, 2/4/5.1/7.1-channel |
LAN | Realtek® GbE LAN (1 Gbps/100 Mbps/10 Mbps) |
Expansion Slots | CPU: 1 x PCIe 4.0 x16; Chipset: 1 x PCIe 3.0 x1 |
Storage Interface | 1 x M.2 PCIe 3.0 x4/x2 (2280/2260), 4 x SATA 6Gb/s, RAID 0/1/5/10 support |
USB Ports | 2 x USB 3.2 Gen 1 (rear), 2 x USB 3.2 Gen 1 (internal), 4 x USB 2.0 (rear), 4 x USB 2.0 (internal) |
Internal I/O | 24-pin ATX, 8-pin 12V, CPU/system fan headers, M.2, 4 x SATA, RGB header, front panel/audio/speaker, TPM, serial, chassis intrusion, Clear CMOS |
Back Panel | PS/2 port, D-Sub, HDMI, 2 x USB 3.2 Gen 1, 4 x USB 2.0, RJ-45, 3 x audio jacks |
I/O Controller | iTE® I/O Controller |
H/W Monitoring | Voltage, temperature, fan/water cooling detection, fan fail warning, fan speed control |
BIOS | 128 Mbit AMI UEFI BIOS; PnP 1.0a, DMI 2.7, WfM 2.0, SMBIOS 2.7, ACPI 5.0 |
Features | GIGABYTE Control Center (GCC), Q-Flash |
Software | Norton® Internet Security (OEM), LAN bandwidth manager |
OS Support | Windows 11/10 64-bit |
Form Factor | Micro ATX; 22.3 cm x 19.3 cm |
